Meunier Technologies DICE Dosing Module

The Meunier Technologies DICE Dosing Module is part of a series of innovative chemical dosing products that integrate all the necessary components for a typical chemical dosing system into a single compact design. These patented modules are a new approach to chemical dosing systems, significantly reducing the footprint required while increasing reliability and ease of installation. The DICE Dosing Module features an extensive set of integrated components including inlet/outlet ball valves, calibration column ball valve, drainage ball valve, auxiliary ports for pulsation dampeners/dilution water/washing port/secondary pumps, an adjustable back pressure valve, adjustable pressure relief valve, pressure gauge with isolator, and bleed valve. All of these components are consolidated into one machined block, greatly reducing potential leak points in comparison with conventional piped systems. This series is designed for suction lift installations or flooded suction configurations (DM only), by connecting the pump’s discharge directly back to the chemical tank. Their compact, rigid design allows easy installation on new or existing systems using just 3 supporting bolts and 4 connections. A variety of construction materials are offered for high chemical resistance, such as Acrylic, PVC, PVDF, FKM/Viton and EPDM(CVPC is available upon request). Reduced connections, vibrations, and integrated hydrotesting allow the DICE Dosing Module to provide a reliable, low-maintenance solution with a much smaller footprint than traditional configurations.
