Druck PACE5000 / PACE6000 Modular Pressure Controller

The Pneumatic Druck PACE5000 / PACE6000 Modular Pressure Controllers bring together the latest
control and measurement technology to offer an elegant fast flexible and economical solution to pressure
control for automated production, test and calibration. The PACE5000 and PACE6000 employ full digital control to provide high control stability and high slew rate,
while its digitally characterized pressure sensor offers the quality, stability, higher bandwidth, and precision
associated with this latest generation of piezo-resistive devices. The PACE series includes: The switch test option automates the testing of pressure switch devices. Following the test, the pressure at which
contacts open and close and the switch hysteresis is displayed. Switch Test Task can also be set to repeat
several times to exercise a switch or capture switch toggle max, min and average values. The leak test option applies a test pressure(s) to an external system connected to the instrument to determine the
magnitude of pressure variations due to leaks. This application sets the test pressure and a dwell time to eliminate
potential adiabatic effects at the test pressure and the leak test time period. On completion, the display shows the
Start Pressure, End Pressure, Pressure Change and Leak Rate. The test program option provides a facility for creating, storing and executing numerous test procedures within the
instrument itself. This is particularly useful for longer, more repetitive and laborious procedures requiring
manual inputs for rapid prototyping, manufacturing and life cycle testing. Test Programs can also be transferred
to a PC using a mass storage device for further editing and copied back from the mass storage device to the instrument. The analog output option can be programmed via the setup menu screen to output a signal proportional to the instrument range
selected. This allows the instrument to interface with PC or PLC I/O cards, remote displays, chart recorders or other
data logging equipment. Users can select outputs of 0 to 10 V, 0 to 5 V, -5 to 5 V and 0/4 to 20 mA. Precision with respect to host instrument
measured pressure 0.05% FS over the host instrument operating temperature range, variable update rate to 80 readings per
second. The option is programmable between minimum and FS pressure for proportional output against pressure. Volt Free Contacts enable control of peripheral devices such as vacuum pumps, ovens, etc. Each VFC option
has three independent volt-free NO/NC relay contacts. A number of conditions can be set within a PACE instrument
to trigger a relay toggling its contacts. The burst test option is an application for the PACE Series designed primarily for the testing of pressure rupture
discs. The burst test option applies a controlled increase of pressure and accurately measures the exact
point at which the device rupture or burst occurs.
