Bently Nevada TK-3 Proximity System Test Kit

The Bently Nevada TK-3 Proximity System Test Kit simulates shaft vibration and position for calibrating Bently Nevada monitors. In addition
to verifying the operating condition of monitor readouts, the TK-3 is also used for both static and dynamic verification of proximity probes.
A properly calibrated system ensures that the transducer inputs and the resulting monitor readings are accurate. The system uses a removable spindle micrometer assembly to check the transducer system
and position monitor calibration. This assembly features a universal probe mount that will accommodate probe diameters from 5 mm to 19 mm (0.197
to 0.75 in). The mount holds the probe while the user moves the target toward or away from the probe tip in calibrated increments and records the
output from the Proximitor Sensor using a voltmeter. The spindle micrometer assembly also features a convenient magnetic base for ease of use in
the field. Vibration monitors are calibrated using the motor-driven wobble plate. A swing-arm assembly located over the wobble plate holds the proximity probe
in place. This assembly uses a universal probe mount, identical to that used with the spindle micrometer assembly. By using the absolute scale factor
of the proximity probe in conjunction with a multimeter, the user adjusts the probe to find a position where the desired amount of mechanical
vibration (as determined by peak-to-peak DC voltage output) is present. No oscilloscope is needed. The user can then compare a vibration monitor’s
reading to the known mechanical vibration signal input viewed by the proximity probe. The mechanical vibration signal from the TK-3 can range from 50
to 254 μm (2 to 10 mils) peak-to-peak.
